E25
- Brand: Enviro
- Product Code: E25
- Availability: In Stock
- E25 Highlight Sheet
- E25 Dimensions
- E25 Owners Manual
- E25 Parts Explodable
- E25 Gas Insert Placard
- E25 Insert Brochure
- Custom Surround Form
Available Options
E25
E25 base model is ready to install with Liner, Log Set, Surround Panel, and Chimney Liner!
ORDERING NOTES
• To complete a unit, you need to order:
1. A body ( ie E25i , includes log set, surround panel, Remote, Fan,
and Chimney liner kit)
• Brick Liner is available separately (not required).
Features
- Steel Liner included.
- Steel Firebox Grate.
- Easy Access Burner Switch (Standing Pilot)
- Standing Pilot or IPI versions available.
- Up to 50% turn down valve.
Options
- (Included) E25 Surround
39" W x 25 3⁄4" H - Trimmable Filler Panel
46" W x 38" H - Brick Liner
- LP Conversion Kit available.
- Hearth Riser
Specifications
Heating Area 1,600 ft²
Max Input BTU (NG) 28,000
Min Output BTU 14,000
Efficiency Coming Soon
Glass Size 420 in²
Convection Fan 110 CFM
Install Dims* 27 7⁄8” W x 19 3⁄4” H x 13” D
Manual
3" Aluminum Liner Only (National Chminey)
National Chimney Aluminum Liner Only Width: 3" ..
E25 Brick Liner (Optional)
E25 Birck Liner (Optional)E25 already comes with&n..
Trimmable Surround Panel - E25
TRIMMABLE SURROUND PANEL - E25 46"W x 38"H..
| General Features | |
| BTU's | 28,000 |
| Heating Area | 1600 sq. ft. |
| Efficiency | 63.9% |
| Unit Dimensions (Height) | 20 1/3" |
| Unit Dimensions (Width) | 27 4/5" |
| Unit Dimensions (Depth) | 13 2/3" |
| Venting Size | 3" Exhaust, 3" Intake... Best used with Duravent 46dva-CL33 Kit w/Duel 35' Liner and Co-Linear Cap |
| Install Dimensions (Height) | 21" |
| Install Dimensions (Width) | 28" |
| Install Dimensions (Depth) | 14" |
| Remote | Included with IPI Models, Optional with Standing Pilot Models |
| Blower | Included, 110 CFM |
